MIL-P-80068D
required in
4 . 8 . 3 . 1 Additional performance tests. Performance tests
addition to or in lieu of he requirements of 4.8.3 shall be as specified and
fully described (see 6.2).
4.8.3.2 Power and manual table tilt test. T h e class A positioner shall
be connected to a power source with a capacity load. The class A positioner
shall be power c y c l e d t h r o u g h a l l t i l t i n g s p e e d s a n d g e a r sequential
i n c r e m e n t s specified in table I and 3.4.3.2. Cycling from
0 through 135
d e g r e e s , the power tilting of the table shall be accomplished through all
t i l t i n g increments in s e c o n d s as specified in table I not less than three
times, and tested, inspected, and verified that the table tilting system meets
or exceeds the requirements specified herein. The class B positioner shall be
connected to a power source with a capacity load. T h e class B positioner
shall be manually cycled through all degrees of tilting and gear sequential
i n c r e m e n t s specified in 3.4.3.3. T h e positioner shall be cycled from O
through 90 degrees for sizes la, lb and 3, and 0 to 135 degrees for sizes 2
and 4. Manual tilting of the table shall be accomplished through all tilting
increments in degrees
as specified in t a b l e II not less than three times.
The positioner shall be tested, inspected, and verified that the table tilting
system meets o r exceeds the tilting requirements s p e c i f i e d i n 3.4.3.3
herein. All performance
any
without making
t e s t s shall be complete
adjustments to or performing any maintenance on the positioner.
4 . 8 . 3 . 3 Noise level test. Noise level measurements shall be made to
ensure conformance with 3.2.5.2. U n l e s s otherwise specified (see 6.2), the
measurements shall be made at the operator's work station and at each "corner
of the positioner. Noise emitted by the positioner when operating under a no
load condition shall not exceed 84 db when measured on the A scale of a type 1
or type II sound meter at slow response. The test shall be conducted with the
positioner operating at intermediate and maximum speeds.
requiring
4 . 8 . 3 . 4 Electromagnetic interference control test. Equipment
electromagnetic Interference control shall be tested for compliance with 3.3.8
using the procedures given in MIL-STD-462.
4 . 9 Environmental protection certification of conformance. The contrac-
t o r shall certify and maintain substantiating evidence t h a t the positioner
offered complies with all environmental protection restrictions as required in
3.2.6. The Government reserves the right to require proof of such conformance
prior to first delivery and thereafter as may be otherwise provided for under
the provisions of the contract.
4.10 Packaging inspection. Packaging of each item shall be inspected to
determine compliance with th e requirements of section 5.
5.
PACKAGING
The requirement for packaging shall be in
5.1 Packaging requirements.
accordance with MIL-W-45562.
NOTES
6.
(This section contains information of a general or explanatory nature that
may be helpful, but is not mandatory. )
